How to Change the Frigidaire Evaporator Fan Motor

Modern frost-free refrigerators route air from the freezer compartment into the refrigerator section.

Change the Frigidaire Evaporator Fan MotorChange the Frigidaire Evaporator Fan Motor
The evaporator fan in the freezer section pulls cold air over the evaporator coil when the compressor is running. If the fan malfunctions, normally the temperature will rise in both the fresh food compartment and the freezer. If you're not able to regulate the temperature in your Frigidaire refrigerator using the controls, a faulty evaporator fan might be to blame. A bad condenser or compressor are other common culprits, but if you've identified a problem with the evaporator fan motor, replace it after verifying that the other components of the fan assembly are functioning properly.

Unplug the refrigerator from the power outlet.

Access the evaporator assembly cover in the rear of the freezer section. In convertible units that can function either as refrigerators or freezers, and is located toward the bottom of the unit on the inner back wall -- if necessary, remove the two lower glass shelves and the crisper compartments.

Remove the screws securing the evaporator cover to the freezer wall, using a Phillips screwdriver.

Pull the evaporator cover away from the wall just enough to access the electrical connection behind the cover. Be careful not to damage the gaskets on either side of the evaporator cover. Reach behind the cover and disconnect the electrical connection from its wiring harness. Remove the evaporator cover from the freezer.

Remove the wires inside the exposed evaporator assembly from their retaining clips, then squeeze the quick-connect mechanism to detach the wires from the fan motor.

Remove the two hex-head screws that hold the fan motor mounting bracket to the back wall of the unit, using a 5/16-inch socket or nut driver.

Remove the two hex-head screws holding the fan motor to the mounting bracket, using the 5/16-inch socket or nut driver, then pull the fan blade off the motor shaft.

Examine the fan to make sure the blades are not damaged; if necessary, replace the fan itself as well as the motor. Slide the fan onto the motor shaft.

Attach the new motor to the mounting bracket, using the 5/16-inch socket or nut driver to secure the two hex-head screws.

Replace and tighten the two hex-head screws that hold the fan motor mounting bracket to the back wall of the unit, using the 5/16-inch socket or nut driver.

Reattach the the fan motor wires by clipping them back into the quick-connect mechanism, and set the wires back into their retaining clips in the same manner as they were attached.

Set the evaporator assembly cover back into place, then reach behind and connect the electrical connection into the wiring harness.

Secure the Phillips screws that hold the evaporator cover to the freezer wall.

Replace the shelves and crisper compartments if they were removed, then plug the refrigerator into its power source and verify proper operation.

Things You Will Need

  • Phillips screwdriver
  • 5/16-inch socket or nut driver

Warning

  • This type of repair is normally performed by qualified service technicians -- always use caution when working with internal refrigerator components such as evaporators and condensers.
