How to Use Poly Tubing in Underground Sprinkler Systems

Underground sprinkler systems make yard work an easy task for many homeowners.

Poly tubing makes installing sprinkler systems easy.Poly tubing makes installing sprinkler systems easy.
When you install it correctly, you can turn on an underground sprinkler system on schedule automatically. While many underground sprinkler systems are made from PVC pipe, these systems can also be made from polyethylene tubing. These pipes are more flexible than PVC and you can install them without adhesive. Learning how to clamp together poly tubing pieces will help you to get your underground sprinkler system operating correctly.

Measure the area of your lawn where you need the poly tubing for the underground sprinkler system. Write the measurements down on a piece of paper.

Transfer the measurements to polyethylene pipes. Cut the piping to size with a scissors-type pipe cutter.

Join lengths of poly piping with barb fittings and crimp rings. Slip the crimp rings onto the polyethylene tubing. Slide the end of the plastic barb fittings into the end of the poly tubing. Move the crimp rings so they fit on top of both the poly piping and the barb fitting. Use crimp-ring pliers to tighten the crimps and secure the barb fittings and the pipes together.

Connect poly tubing to sprinkler heads with 90-degree fittings that have barbed fittings on one and a female thread on the other end. Connect the tubing to the barb fitting with crimp rings and crimp-ring pliers. Install the sprinkler head per manufacturer directions.

Things You Will Need

  • Measuring tape
  • Paper
  • Pencil
  • Polyethylene pipes
  • Scissors-type pipe cutter
  • Barb fitting pieces (straight and 90-degree angle pieces)
  • Crimp rings
  • Crimp-ring pliers
  • Sprinkler heads
