How to Install Stairs on a River Bank
Property owners whose land touches a stream or river must often plan for a sustainable means to access the water. A simple footpath without reinforcement can lead to serious erosion and make accessing the water for swimming, canoeing or other purposes difficult.
To prevent or deal with bank erosion and ensure long-term access, stairs can be constructed on the bank. Stairs made out of pressure-treated timber, when properly installed with rebar and protected from the current, are aesthetically pleasing and relatively inexpensive and easy to install and repair.
Things You Will Need
- Measuring tape
- Framing square
- Pencil or marker
- Pressure treated timbers
- Angle braces (4 inch by 4 inch, 2 inches wide)
- Lag bolts (3/8 inch)
- 10-inch galvanized steel spikes (3/8 inch)
- Mattocks, shovel and other digging and excavating tools
- Rebar (4-foot lengths)
- Gravel or other fill
- Rip rap (large rocks)
Consult governing jurisdictions before beginning construction on a river bank. Typically, local, county or state governments regulate projects next to bodies of water and require permits.
Determine the number of steps that will be required. Hold a level board or string at the top of the sloped bank that extends over the bottom of the bank to where the lowest step will go and measure the distance between the ground and the level board to determine the total rise. Use this number as well as the total run that the steps must cover, or the horizontal distance between the bottom and the top of the area, in combination with the desired tread size, to calculate the number of steps that will be required.
Cut timbers to the required lengths. Take the length of the uncut timber into consideration. For example, if the uncut timbers are 8 feet, it may be ideal to make the step timber and the tieback sections all 4 feet.
Assemble the treads by attaching three lengths of timber, essentially creating a "U" for the front and sides of each step. Use angle braces and 3/8-inch lag bolts to join the sections together. Drill two 3/8-inch holes on each end of the front of the tread and use a sledgehammer to pound 3/8-inch steel spikes into the holes.
Excavate the area for the stairs. Wait to disturb the area by digging and removing earth until shortly before the steps can be installed to limit erosion. Create the rough shape of the staircase. It may be necessary to excavate the area further as the steps are installed.
Set the timber tread for the first step. Make sure that it is level. Add or remove fill as needed to correct any unevenness. The first step should be almost entirely buried in order to act as a solid base for the steps on top of it.
Attach the timber tiebacks to the ground with rebar. Drill a hole near the end of each tieback and pound a 4-foot length of rebar through the hole into the ground.
Build the rest of the steps until the top of the bank and the planned staircase top is reached. Place each U-shaped timber outline on top of the step below it, make sure it is level, drill holes on the the upper tread about four inches from each end and pound a spike through each hole to tie the steps together. Drill a hole through the back of each tie and pound rebar through it.
Fill the spaces for the treads with gravel or a gravel mixture. It may be most convenient to fill in the tread spaces as the stairs are constructed in order to create a level working space.
Place rip rap, or large rocks or boulders, at the base of the base of the stairs and otherwise stabilize the site. The large rocks will help to protect the lowest step from undercutting. As an alternative or in addition to large rocks, a vegetative buffer can be implemented upstream and around the base of the stairs. Vegetate any disrupted areas of the bank next to the stairs as quickly as possible to avoid erosion.
When selecting timbers for the stairs, choose only wood treated with a preservative that can be in contact with freshwater such as copper azole.
