DIY Tatami Bed Frame

Incorporate traditional Japanese design into a modern setting with a low-to-the-floor bed frame topped with a foam mattress and a tatami mat.
Tatami beds utilize tatami mats for comfortable sleep.Tatami beds utilize tatami mats for comfortable sleep.
Tatami mat is traditional Japanese flooring made with a rice straw core and a rush straw outer woven layer. This simple bed is the perfect addition to any apartment or home, and its relatively small and straightforward design makes it particularly suited to small dwellings. These plans for a tatami bed can easily be completed over the course of a weekend, and can be customized to fit any size western or Japanese mattress.

Step 1

Stand six 2-by-2-by-6 inch wood blocks up on their ends and set a 3/4-by-43-by-79 inch plywood sheet on top of them. Spread the wood blocks out so that one is in each corner of the sheet with its outside edges flush with the outside edges of the plywood, and the other two blocks are centered along the longer sides of the plywood sheet. Set the outside edge of the two centered blocks even with the outside edge of the plywood sheet on that side.

Step 2

Drill two evenly spaced holes down through the plywood sheet and into each block. Attach the blocks to the plywood sheet with 2-inch wood screws tightly fastened.

Step 3

Arrange two 1-by-3-by-43 inch boards parallel to each other, about six feet apart. Set two 1-by-3-by-77 inch boards between them, perpendicular to the shorter boards but parallel to each other so that the four boards form a rectangular frame with the shorter boards on either side of the longer boards. Drill two evenly spaced holes through the larger outer surface of each of the smaller boards and into the end of each of the longer boards. Attach the boards together with 2-inch wood screws.

Step 4

Flip the plywood sheet upside down and set it on the four boards, arranging the frame so that it is evenly spaced on the rectangular board arrangement. Predrill evenly spaced holes every 12 inches around the outside edge of the plywood sheet and into the boards underneath. Attach the boards with 2-inch wood screws.

Step 5

Flip the bed frame over and place a 4-inch foam mattress within it. Top with a tatami mat.

Things You Will Need

  • Plywood sheet - 3/4-by-43-by-79 inches
  • 6 leg boards - 2-by-2-by-6 inches
  • Drill
  • Drill bits
  • 2-inch wood screws
  • 2 boards - 1-by-3-by-43 inches
  • 2 boards - 1-by-3-by-77 inches
  • 4-inch foam twin mattress
  • Tatami mat

Tip

  • Paint or stain the entire assembled bed frame for an uniform appearance.

Warning

  • Do not jump on this bed, as it is not designed to handle the stresses and forces of jumping.
