How to Make a Chain Harrow

How to Make a Chain Harrow
Published: Feb 23, 2011
Updated: Nov 20, 2021
2 minute read

If your lawn has seen heavy use, use a chain harrow to remove clods of earth that have been kicked up and for aeration of the lawn.

Things You Will Need

  • Arc welder
  • 2 three-foot pieces chain
  • 5-inch ring
  • 4 four-foot pieces of metal tubing 2-inches thick
  • Disc cutter
  • 5 four-foot pieces chain
  • 72 nine-inch nails
  1. Weld an end of the 3-foot pieces of chain to to the end of one of the metal tubes. Weld the other ends to the 5-inch ring. The end result should look like a triangle with two sides the same length. This is the tow bar.

  2. Cut the ends of the each pipe, including the one attached to the chains, at a 45-degree angle. When put together, the pipes should form a perfect square. Weld the pipes together.

  3. Weld the 4-foot chains to the tow bar 8 inches apart. Weld the other end of the chains to the opposite side. Ensure the chains are tight.

  4. Put the first 3 nails through a chain link, 6 inches from the tow bar. Make sure they form a pyramid shape. Each nail should be 6 inches from the other nails in the same pyramid. Weld them onto the chain. Repeat this at 12-inch intervals, working down each chain. There should be 24 of these tines.

  5. Attach the harrow to your lawnmower, horse or tractor. Drive at a fast walking pace, to ensure the ground is suitably harrowed.

The Drip Cap

  • Regular maintenance of lawns and plots is essential to ensuring good fertility and that debris is removed.
  • If your lawn has seen heavy use, use a chain harrow to remove clods of earth that have been kicked up and for aeration of the lawn.
  • Weld an end of the 3-foot pieces of chain to to the end of one of the metal tubes.
  • When put together, the pipes should form a perfect square.
