How to Build a Firewood Bundle Wrapper
Wrapping firewood in shrink wrap is useful if you want to sell it, as it increases the bundle's attractiveness and allows customers to see the wood. Doing this by hand can be a clumsy task, however. You will get much better results by building a bundle wrapper. This device is essentially a bowl that holds the firewood while an arm holding shrink wrap spins around it. It will allow you to bundle firewood quickly and efficiently.
Sand the ends of all PVC pipes.
Apply a bead of PVC glue into the four lower flanges of a 1-inch 5 way PVC joint, leaving the top flange unglued.
Insert an 8-inch PVC pipe into each glued flange, wiping away any excess glue with a paper towel.
Glue four 1-inch PVC end caps onto the other sides of the pipes.
Glue a 5-inch PVC pipe into the joint's fifth flange to create the wrapper's stand.
Slip a 1 1/2-inch 3-way T Joint onto the 5-inch pipe, with the side flange facing out. It should be loose, allowing it to rotate freely.
Place a 12-inch PVC end cap facedown on a table, like an upside-down bowl.
Place a 1-inch PVC end cap faceup onto the center of the 12-inch cap's bottom.
Drill a quarter-inch hole through the center of both caps.
Thread a quarter-inch bolt through the larger end cap and smaller one. Tighten the nut within the 1-inch end cap to join the two together.
Place the 1-inch end cap onto the 5-inch pipe. This creates a 12-inch bowl resting on the PVC stand. Do not glue the cap; you will want to remove it periodically to tighten the nut.
Glue an 18-inch piece of 1 1/2-inch PVC pipe and a 6-inch piece into opposite ends of a 4-way joint.
Glue a 1 1/2-inch elbow joint to the other side of the 6-inch pipe.
Glue a final 6-inch piece of 1 1/2-inch pipe into the other side of the elbow joint. This completes the arm that will hold the roll of shrink wrap.
Glue the 6-inch pipe into the side flange of the rotating T-Joint.
Allow all of the glue to dry overnight.
Things You Will Need
- 1-inch 5-way PVC flange
- PVC glue
- 1-inch PVC pipe, 8 inches long (4)
- 1-inch PVC end caps (5)
- 1-inch PVC pipe, 5 inches long
- 1 1/2-inch PVC T-Joint
- 12-inch PVC end cap
- 1/4-inch drill bit
- 1/4-inch bolt and nut
- 1 1/2-inch PVC pipe, 18 inches long
- 1 1/2-inch 4-way PVC joint
- 1 1/2-inch PVC pipe, 6 inches long (2)
- 1 1/2-inch PVC elbow joint
- To use the bundle wrapper, slide a roll of shrink wrap onto the rotating arm. It will rest on the 4-way joint. Stand firewood in the upward-facing 12-inch PVC end cap. Staple the end of the shrink wrap to a piece of wood, then spin the arm around the bundle several times.
