How to Install a Lift Rod in a Bathroom Sink
You do not need tools to install or adjust the lift rod assembly in your bathroom sink, meaning you should be able to complete the task in less than 20 minutes. You will likely need to adjust the assembly in order to ensure that the pop-up stopper in the sink sits high enough to allow the water to drain when you push down on the lift rod, as well as sit low enough to keep the water in the sink when you pull up on the lift rod.
Drop the pop-up stopper into the sink's drain opening, allowing the stopper to sit in the closed position. Insert the narrow end of the lift rod into the hole in the top of the sink's faucet.
Allow the sink's lift rod to drop until the handle on the top rests on the top of the faucet. Slide the U-shaped end of the clevis over the narrow end of the rod.
Twist the retaining nut on the clevis clockwise to securely attach it to the lift rod. Slide the circular retaining nut over the long, narrow end of the pivot rod, making sure the threads on the nut point toward the end of the pivot rod that is shorter and has a ball.
Insert the long, narrow end of the pivot rod through one of the holes in the clevis. Insert the narrow end of the pivot rod into the opening in the sink's drain pipe, stopping once the large ball on the pivot rod sits inside the pipe.
Slide the retaining nut on the pivot rod into the opening in the sink's drainpipe. Thread the retaining nut on the pipe's opening by twisting the nut clockwise. Fill the sink with at least an inch of water to make sure the stopper seals correctly. Adjust the stopper by threading the end of the pivot rod through another hole in the clevis.
Things You Will Need
- Pop-up stopper
- Lift rod
- Pivot rod
- Retaining pipe nut
