How to Troubleshoot Senco Framing Nailer

Senco is a major manufacturer of nail guns, including pin nailers, finish nailers and framing nailers.

Air Supply Problem

A framing nailer is much faster than a traditional hammer.A framing nailer is much faster than a traditional hammer.
Framing nailers are the work horse of the framing world, making short work of frame carpentry chores. A properly maintained Senco nailer will operate trouble free most of the time, but there are a few troubleshooting tips you can use to avoid expensive repair bills. The most common problems are bad air supply, jammed fasteners and the inability to set the nails fully.

Check the compressor to ensure it is turned on. Pull the release valve to discharge the pressure and restart the compressor. Allow it to fill until it stops and test the nailer again. If this fixes the problem, return to normal use, if not, continue.

Disconnect the air hose before beginning troubleshooting. Pull the feeder shoe toward the bottom of the nailer along the magazine until it locks in place. Make sure there are nails in the magazine.

Inspect the top of the magazine for jammed fasteners. Unsnap the latch on top of the nailer and fold it open. Remove jammed fasteners with a small screwdriver, then close the top.

Push the fasteners up to the top of the clip and release the feeder shoe so the spring carries it up against the fasteners.

Apply three drops of tool oil into the air intake at the bottom of the nailer handle. Reattach the air hose and resume normal use. If the problem persists, see a professional tool service for repairs.

Fasteners not Seating Fully

Disconnect the air hose. Inspect the magazine as outlined above. Make sure the fasteners are set with their points at the front of the clip, and adjust if needed.

Check the compressor to make sure it is set at the correct air pressure. Adjust the pressure gauge as needed for optimum operation.

Tighten the screws holding the back vent cover on the nail gun at the top rear of the handle. Use an Allen wrench to turn them clockwise to tighten.

Reattach the air hose, start the compressor and allow it to charge fully. Test the gun, and if the problem persists seek professional servicing.

Things You Will Need

  • Fasteners
  • Allen wrench
  • Tool oil
