Miller Welder Onan Engine Specifications

Onan engines provided the power to Miller welders.

Founded in 1929, Miller Electric Mfg.  Co. produces welding equipment in Appleton, Wisconsin.  Miller Welders used Onan engines which were produced exclusively for its company's welding equipment and Lincoln Welders, another welding company. Today Cummins Onan no longer manufactures engines but still services Miller Welder Onan engines and provides replacement parts.  The Miller Welder engines, like the Onan OHV 20, were built to strict specifications.

Dimensions

The Onan OHV 20 engine is 1248 inches, or 317 mm long and 1878 inches, or 477 mm, wide.  The final dimension, height, comes to 1870 inches, or 475 mm. The engine weighs 969 pounds or 44 kg.  Its displacement measures 3990 cubic inches.

Horsepower

The engine has a rated output at 3,600 rpm of 205 horsepower.  Its continuous output at 3,600 rpm is 16 horsepower. With a compression of 84:1, the Onan generates a maximum torque at 2,200 rpm of 327 foot-lb.  The engine's bore, or diameter of the cylinder in which the piston moves up and down, measures 315 mm. The stroke, or the distance the piston moves, is 256 mm.

Fuel Use

When the Onan engine is at full load it consumes 196 gallons of fuel per hour.  At one-half load the consumption drops to 114 gallons per hour. For three-quarter load the engines uses 152 gallons per hour.

Oil Use

The Onan engine has a capacity of 164 quarts of oil.  It comes equipped with a full-flow spin-on oil filter along with full-pressure lubrication. To avoid any damage it comes equipped with a low oil pressure cutoff switch.

Special Features

The Onan OHV 20, representing over 50 years of engine design experience, features cast iron cylinder sleeves.  It also comes equipped with a large dual-element air cleaner. Other feature include a pulse-type fuel pump, fixed-speed governor, electronic ignition and 12-volt solenoid shaft starter.  Each engine carried a three-year limited warranty that could be expanded to five years. The engine met all government environmental standards at the time of its manufacture.  According to Cummins Onan, the age and condition of the engine, its use and maintenance all determine whether or not it still complies with emission regulations.
