How to Attach a Propane Torch to a Twenty Pound Tank

Propane Torch Assembly

1. Wrap pipe thread tape around the male threads of the hose connector (attached to the propane torch handle), working the tape 3 inches along the threads.

2. Secure the torch to the hose by fitting the handle connector (attached to one end of the hose) onto the hose connector; tighten it firmly, using the open-end wrench.

3. Turn the hand wheel (on the torch handle) clockwise to the "off" position.

Attachment to Propane Tank

1. Ensure that the valve on the propane tank is turned completely off.

2. Insert the cylinder connector (on the opposite end of the hose) into the hose connector on the propane gas tank and screw it firmly in place with your hand. Use the wrench to make the final turns, but avoid overtightening.

3. Begin the flow of propane by slowly turning the hand wheel counterclockwise. Light the torch by inserting a long match through one of the slots located on the burner portion of the torch.

References

• Harborfreight: Propane Torch, Assembly and Operating Instructions
• This Old House: How to Use Torches, Heat Guns, and Soldering Irons-and When

Show More

Tips

Clean the torch parts and propane tank with water and a mild detergent.

Turn the hand wheel on the torch to "off" and let it cool down before storing it. Always store it away from flammable items.

Show More

Warnings

Periodically check the hose for cracks; if any exist, replace the hose immediately.

Ensure that all connections are tight and parts are not damaged before each use. Do not use the torch if it or the tank is damaged.

Use the propane torch outdoors only -- to avoid carbon monoxide poisoning.

Show More
