Install The Cable For A Curtain Wall
Measure the cross walls and mark the location where you want to install the cable hardware for your curtain wall. Mount your cable close to the ceiling for the maximum wall effect. The cable should be attached directly into a stud for stud walls or into the block portion of a concrete block wall. Mark your locations on each opposing wall.
Screw a heavy-duty screw hook directly into a wood stud for stud walls. Drill a pilot hole if the screw hook is too difficult for you to turn by hand. Drill a hole for a masonry wall anchor with a hammer drill. Use a one-piece expansion anchor for solid concrete walls. Use a metal-sleeve type anchor for hollow concrete block walls. Screw the hooks into the anchors.
Loosen the turnbuckles to the maximum open position. Thread cable through the loop end of the turnbuckle. Use cable wire rope clips to connect the end of the cable to the main part of the cable. Leave an extra 6 inches of cable on the short side. Place the hook end of the turnbuckle onto the screw hook mounted in the wall.
Stretch the cable across the basement. Hook the loosened and open the turnbuckle to the wall hook. Thread the cable through the loop end of the turnbuckle. Pull the cable to make it as tight as possible. Use cable wire rope clips to connect the end of the cable to the main (stretched) part of the cable. Leave an extra 6 inches of cable on the short side. Cut off the excess wire with cable cutters.
Tighten the cable more by turning the turnbuckles to tighten or shorten the distance inside the turnbuckle.
Attach ring and clips to the cable. You will need 8 to 10 rings per standard-width curtain panel (approximately 60 inches of fabric).
Make Simple Curtain Panels
Pre-wash your curtain fabric and iron the fabric before making your curtain panels. This will prevent later shrinkage.
Measure the height from the cable to the floor and add 1 inch. Use the width of your fabric for individual panels or sew the sides together for wider curtains. For individual panels hem around all four sides with a 1/2 inch hem. For joined panels hem the top and bottom edges and seam along the sides to attach as many panels together as you like.
Attach your curtain panels to the cable by evenly spacing the alligator clip portion of the curtain rings to the top edge of the curtain panels.
Things You Will Need
- Tape measure
- 2 screw hooks
- 2 wall anchors (optional)
- Plastic-coated aircraft cable
- Cable cutter
- 2 turnbuckles
- Wire rope clips
- Iron and board
- Sewing machine
- Consider buying fabric by the bolt to cover long walls at a discount.
