How to Mount an Aqua Source Shower Faucet

The Aqua Source shower faucet is a single-handle faucet that mounts to your shower wall.

A single-handle faucet allows you to easily blend hot and cold water.A single-handle faucet allows you to easily blend hot and cold water.
When you pull the handle and rotate it, you select between a blend of hot and cold water. For this reason, when installing an Aqua Source faucet in your shower, you need to make sure your shower's plumbing is set up correctly. Both hot and cold water supplies must merge into the threaded pipe that rests in the center of the hole for your faucet.

Locate and remove the access panel for your shower's plumbing. If you do not have an access panel built in, use a keyhole saw and remove a section of drywall to gain access to the plumbing. Inspect the plumbing. The threaded pipe that extends to the backside of your shower wall must have a hot and cold water supply connected to it. If not, your shower's plumbing is configured for dual valves, or a single hot and single cold valve.

Wrap plumber's tape around the threaded end of the pipe inside the wall.

Slide the valve through the hole in the wall and thread it onto the pipe with your fingers. The pipe has NPT, or national pipe thread. These threads taper and get larger as you turn. This makes it hard to turn the valve onto the threads. Once you get to the point where you cannot turn it with your fingers, turn the valve with a pipe wrench.

Thread the jam nut located on the threaded pipe toward the back of the faucet valve, and tighten it with a wrench.

Slide the cover plate onto the valve to cover the hole in the shower wall, and secure it with the supplied screws and a screwdriver.

Slide the handle onto the valve, and then secure it by tightening the set screw on the side of the handle.

Things You Will Need

  • Plumber's tape
  • Pipe wrench
  • Standard wrench
  • Screwdriver
