How to Put a Blade on a Stihl Trimmer
Stihl trimmers have interchangeable cutter heads that allow you to switch back and forth from stringed cutters to blade cutters. Grass and weeds yield easily to string, but thick brush calls for a blade. Stihl trimmers are designed to convert easily to blade cutters for heavier, string-breaking trim jobs.
The process of switching from string to blade cutting is relatively straightforward.
Things You Will Need
- Locking pin (supplied with the trimmer)
- Wrench
- Stihl cutter blade
- Stihl cutter blade shroud
Warning
Wear gloves to protect your hands from sharp blades while changing your trimmer head.
Never operate your trimmer without the protective cover or blade shroud on the staff.
Wear gloves, safety goggles, protective clothing and protective boots when using your trimmer. This protects against injury should something fly back toward you. Always keep your work area cleared of children and pets.
-
Pull the cap off the spark plug to keep the trimmer from accidentally starting. Place the Stihl trimmer upside down so you can easily access the black cutter head assembly.
-
Push the locking pin into the side of the cutter shaft, and rotate the cutter head until the locking pin locks in place.
-
Remove the knurled plastic bump-down button from the cutter head assembly by turning it clockwise.
-
Pull the string spool off the shaft. Remove the nut that holds the spool cover onto the shaft with a wrench, and then pull the cover off the shaft.
-
Place the blade shroud onto the trimmer shaft, then place the blade onto the trimmer shaft. Secure the blade and the shroud firmly onto the trimmer shaft with the nut you previously removed. Remove the locking pin from the cutter shaft.
The Drip Cap
- Stihl trimmers have interchangeable cutter heads that allow you to switch back and forth from stringed cutters to blade cutters.
- Stihl trimmers are designed to convert easily to blade cutters for heavier, string-breaking trim jobs.
- Remove the nut that holds the spool cover onto the shaft with a wrench, and then pull the cover off the shaft.
