How to Change a Skil Miter Blade

Miter saws make precise cuts for picture frame corners.

Skil miter saw blades become dull after hours of use, and require replacements for a clean cut that doesn't rip the wood.

1. Unplug the saw.

2. Push the miter arm assembly down and lock it in the lower position. Lift the lower blade guard up and loosen the front screw on the guard with a screwdriver. Do not remove the screw. Remove the rear guard screw.

3. Unlock the blade guard and raise the arm assembly up while holding the lower guard upward. The blade bolt is now exposed. Push in the arbor lock on the top right side of the guard to hold the blade in position.

4. Remove the blade bolt. Pull the blade collar and the blade straight off the saw.

5. Place a new blade on the saw with the arrow pointing forward. Replace the collar with the flat side touching the blade. Insert the bolt into the blade and tighten it.

6. Pull the miter arm assembly down in the lower position and lock it in place. Align the rear of the blade guard with the rear screw hole. Insert the screw and tighten it. Push the lower guard up into position and tighten the front guard screw.

7. Push the arbor lock to release it.

Tip

The blade bolt is a left-hand bolt. Left hand bolts tighten counterclockwise and loosen clockwise. Use the spanner wrench in the on-tool saw storage area to remove the blade bolt instead of adjustable pliers.

Warning

Replace miter saw blades with the same-size blades. Larger blades will not turn smoothly in the guard, and will bind the motor.
