How to Program Genie Garage Door Opener ISD1000

Genie Garage Door Opener ISD1000 is a model with a digital wireless keypad. The keypad is programmed to communicate with the garage door opener, allowing the homeowner to open the garage door by simply pressing a button. Program the digital wireless keypad after the initial installation of the Genie garage door opener.

If additional keypads are used, program each additional keypad. If the wrong PIN (personal identification number) is entered, reset the keypad.

Reset the Keypad to Factory Settings

  1. Open the cover on the keypad halfway.

  2. Press and hold the “8” key while opening the keypad cover fully. The indicator light will blink once to indicate the keypad was reset.

  3. Close the keypad cover. The keypad is ready for programming.

Program the Garage Door Opener and Keypad

  1. Open the keypad cover completely. The indicator light will blink one time.

  2. Press the “3,” “5” and “7” keys, in that order. Press the “Prog” key. The indicator light will blink once per second. Enter the desired personal identification number (PIN) on the keypad. Press the “Prog” key. The indicator light will blink two times every second. Close the keypad cover.

  3. Press the “Learn Code” button on the garage door opener. It is located on the rear panel or under the light cover. The LED light will flash.

  4. Open the keypad cover completely and enter the selected PIN. Press the ‘Send” button until the door operates.

Program the Keypad for Multiple Doors

  1. Program the garage door opener and keypad as instructed above. Open the keypad cover fully and enter the PIN. Press the “Prog” key three times. The indicator light will blink three times per second.

  2. Press the number key on the keypad that corresponds with the number of doors you wish to program. Press the “Prog” key and close the keypad cover completely.

  3. Press the “Learn Code” button on the second garage door opener. Open the keypad cover completely and enter the PIN. Press the “Send” key and press the “2” key. Press the “Send” button until the door operates. Press the “Learn Code” button on the third garage door opener, if applicable. Open the keypad cover completely and enter the PIN. Press the “Send” key and press the “3” key. Press the “Send” button until the door operates.

Opening Garage Doors with the Keypad

  1. Open the keypad cover and enter the PIN on the keypad.

  2. Press the “Send” key to open the garage door. If the keypad controls multiple doors, proceed to Step 3.

  3. Press the door number on the keypad to open the appropriate door.
